AHA-10

Recessed Access Door without Flange

key operated cylinder cam latch, piano hinge

Designed with a 5/8″ recessed door, this panel accepts ceramic tiles, acoustical tiles or any other type of material in order to blend in with the surface finish. A key operated cam latch ensures a higher level of security.

  • Installation Walls and ceilings
  • Material Cold rolled steel
  • Locking mechanism Key operated cylinder cam latch
  • Hinge Piano hinge
  • Flange No flange
  • Size Other sizes available upon request

Quantity

Specifications

  • Material

    16 gauge cold rolled steel

  • Hinge

    Continous piano hinge. Hinge location: Hinges must be located on the second dimension (height).

  • Locking mechanism

    Key operated cylinder cam latch with two keys per lock

  • Flange

    Without flange

  • Frame

    1 5/8 " in depth, made of cold rolled steel

  • Rough opening

    Door sizes + ¼ " or + 6mm

  • Finish

    High quality white powder coat primer

  • Packaging

    Individually wrapped, 1 door per box

Dimensions

Dimensions (Inches)Dimensions (Millimeters)Weight (LBS)Weight (KG)Number of locks
* 8 X 8203 X 2033.41.51
* 12 X 12304 X 3045.82.61
* 16 X 16406 X 4068.73.91
* 18 X 18457 X 45710.54.81
* 24 X 24609 X 60917.47.91
* All dimensions are written in the following order: Width X Height

Technical drawings
